Product Description:
The series injection type and normal pressure gravity type dual-use filling machine is a high-cecn product researched and developed by our company. It is suitable for products of various viscosity such as water injection, semi-fluid and ointment etc. It is widely appied for filling of products in such industries as food, cosmetics, medicine, grease. daily chemical industry, detergent, pesticide and chemical industry etc. By adopting piston line filling mode, it can be full solutions of different types without the need of adding any spare parts.
Main Features:
1, The series machine have the compact and reasonable design with perfect apperance.
2, It is made of electrical components of internationall famous brands. Then main actuating cylinder adopts Germany FESTO dual actuating cylinder and magnetic switch.
3,Japan Mitsubishi PLC computer, Ormon photoelectric eye and touch screen made in Taiwan, all of which have guaranteed the excellent quality and consistently stable performance of the machine.
4,The machine can be maintained conveniently. It can be easily assembled, disassembled and cleaned without any tools. The adjustment is convenient. For the measurement adjustment, firstly adjust at large scale to be close to the measurement and the carry out fine adjustment. It can be readized that no filling in case of no bettle or bottle or insufficient bottle and accurate measurement.
5,The filling system of the machine adopts furrule type rapid installation connector. The whole cyliner can be easily assembled, disassembled and cleaned from top to bottom without any tools. The structure is simple in design and convenient in operation and maintenance.
Technical Parameter:
| Model | YHZDGZ-HS(6-8-10 Heads) |
| Filling Speed | 80-100 b/min (250ml/10 heads) |
| Filling Precision | ±1% |
| Cylinder Body Size | 25-250ml/50-500ml/100-1000ml/250-2500ml |
| Air Suppier | 5-7kg/m² |
| Weight | 950kg |
| Dimension | 2000X810X2200mm |
